Cardiovascular Stent Tubing

Cardiovascular Stent Tubing

Tech Tube was approached by a client in the medical industry and asked to manufacture high precision cobalt cardiovascular stent tubing. The tubing was first prototyped through an exacting product engineering and support process.

We managed the entire production of the tubing, from the initial melt through to the final product. Extruded tube could not meet the client’s requirements, so we used custom bar stock and gun drilled the raw materials to create the finished tube. The tubing then underwent medical-grade cleaning and a specialized annealing process. The detailed inspection process included checks for concentricity, wall runout, eddy current, chemistry, mechanical properties, and 100% straightness verification. The tubing’s critical medical applications left no room for error. Throughout the entire delicate process, we maintained the tightest tolerances. Each year, we produce enough tubing to support the manufacturing of over 3 million medical stents.

For more information about this high precision project, see the details below. To learn about our other services, please contact Tech Tube today.

Cobalt Cardiovascular Stent Tubing Project Specifications

Product Description This cobalt tubing is used as cardiovascular stent tubing. This is high precision medical grade tubing.
Capabilities Applied/Processes
Primary
Tube Drawing
Medical Cleaning Process
Special Annealing Process
Precision Straighten
Product Engineering & Support
  • Prototype
Bar Melting
Gun Drilling
Secondary
O.D. Polishing
Burr-Free Cutting
Special Inspection
  • Concentricity
  • Wall Run Out
  • Eddy Current
  • Chemistry Verification
  • Mechanical Property Verification
  • Straightness
  • 100% Straightness Verification
Material Used Cobalt Chromium
Material Finish 8 Ra OD
16 Ra ID
Special Features Implantable Grade
Industry for Use Medical
Packaging Special Cleaning
Packaging in Plastic Tubes
Volume 3 million per year
Delivery Time Kanban
Delivery Location Worldwide
Standards Met Customer Specifications
ISO
Product Name Medical Stent Tubing
